Unlimited agility and swiss knife versatility for great trail riding adventures
Dynamic and comfortable
Full carbon rim offers great lateral stiffness Enhanced fiber lacing gives maximum vertical compliance
The two-cross spoke pattern on the front and rear offers comfort and control
Next generation Trail weapon
Light and strong, full-carbon rim with hookless profile and tubeless tape 26mm internal and 28mm
external width
The right link
-Quest Pro tire in 2.4 -Reinforced casing : Guard, protection and comfort -X-mix dual compound : safe
grip and fast rolling
リム プロファイル
Material: 100% Unidirectional carbon fiber
Drilling: traditional
Valve hole diameter: 6.5 mm
Tyre: UST Tubeless and tubetype
Internal width: 26 mm
ETRTO size 27.5": 584x26ss
ETRTO size 29": 622x26ss
Hookless profile
Use with Mavic Tubeless Tape
スポーク
Material: steel
Shape: straight pull, bladed, double butted
Count: 24 front and rear
Lacing: front and rear crossed 2
ハブ
Front and rear bodies: aluminum
Axle material: aluminum
Adjustable sealed cartridge bearings
Freewheel: ITS-4 alloy
タイヤ
Quest Pro
UST Tubeless Ready
Front and Rear Tread: Dual Compound
Casing: 127 TPI
Dimension 27.5": 2.40
Dimension 29": 2.35
種類
Color: Black only
Disc standard : 6 Bolts only
Hub width : Boost (front 110, rear 148) or Non-Boost (front 100, rear 135/142)
対応
Freewheel: Shimano/Sram, convertible to XD with optional driver body
Front axle: convertible from 15mm thru axle to Quick Release with included adapters
Rear axle: 12mm thru axle, convertible to Quick Release with optional adapaters
付属品
1 bottle of Mavic Sealant
BX601 quick releases
Front QR adapters
Rear 12x142mm adapters for ITS4 and TS2
UST valve and accessories
Tubeless rim tape
Multifonction adjustment wrench
User guide
ラベル
SSC
用途
ASTM CATEGORY 3 : offroad with jumps less than 61cm
For a longer longevity of the wheel, Mavic recommends that the total weight supported by the wheels don't exceed 120kg, bike included
Recommended tyre sizes: 35 mm to 69 mm (1.4" to 2.7")
フィルター
Category : Trail
Diameter : 650b/27.5"
Diameter: 29"
Front Axle: 15mm
Front Axle: 15x110 (Boost)
Rear Axle: 12x135/142
Rear Axle: 12x148 (Boost)
Rim width (internal): 25 to 26mm
UST: yes
weight: 1301g to 1500g
効率性/剛性
ITS-4
UST Tubeless Ready
X-mix
QRM+
安全性/信頼性
Guard +
トレイルライドでは、下りを楽しむことができるよう、登りではできるだけエネルギーを温存することがポイントになる。優れた設計のカーボンホイールなら、登りでも下りでも申し 分のない性能を発揮する。だがカーボンホイールは縦方向の追従性が貧弱なため、ハンドルの操作性が悪く、トラクションが失われているというのが、レーサーたちのフィードバックだ った。 そこでXAプロ カーボンの開発時には、どんなアルミホイールよりも大幅に軽量化しているだけでなく、横剛性と耐衝撃性に優れ、十分な縦方向の追従性も備えたものにすること が目標となった。 この目標を達成するため、マヴィック独自のフィニット エレメント シミュレーション ソフトウェアを駆使し、軽量性、耐衝撃性、横剛性、縦方向追従性のバランス がベストになるリムを実現した。 フックレスリムによる高い互換性 ホイールを最も一般的なトレイルタイヤ幅(2.3〜2.4インチ)に対応させるため、最高のパフォーマンスを発揮する 26mmフックレスのリム形状とした。USTチューブレスタイヤにフル対応なので、トラクション、パンク耐性、使いやすさすべてが向上し、特別設計のリムテープも貼られている。 アシン メトリーなリム マヴィック独自のホイールシステムは、スポーク組の微調整が可能なので、リムの特徴がより活かされる。スポーク張力のバランスを良くするため、リムをアシンメト リ ー(左右非対称)にした。スポークは、2面性を持つ構造のスチール製スポーク24本をフロントもリアも両サイドで3本を交差させ、ここでも横剛性と縦方向追従性のスイートスポッ トを 見つけ出した。 27.5インチはわずか1,490g、29インチも1,535gのXA プロ カーボンは、要求の厳しいライダーも納得のこのカテゴリー最軽量クラス。 自分仕様のセットアップに このホ イールには幅広い汎用性のクエスト プロ タイヤが用意され、直径27.5インチは2.4インチ幅、直径29インチは2.35幅インチになっている。ハブは6穴ボルトのみだが、スタンダ ードタイ プ(15x100&12x142)とブーストタイプ(15x110&12x148)がある。フリーホイールは、シマノ/スラムのスタンダードまたはXD(スラム イーグルと互換性あり)に対応。ま たキャノン デールのレーシングバイク用にレフティ60フロントホイールもある。
